Metalunic Sinus

Products

Metalunic Sinus - The all metal external venetian blind Sinus from Griesser

Description

The flowing form of the Metalunic Sinus can be harmoniously integrated into any facade and is ideal for a trendy, contemporary look in home furnishings. The Sinus slats direct sun rays to the ceiling. In doing so, the effect of the light reflected by the curved slats reduces glare on work spaces. Metalunic Sinus offers two things in one: use of existing daylight and comfortable glare protection.

Discover Soft-Closing:

Contact

Send a message now

Any questions?
Call us.

+43 5525 64222-0

Documents

Planning

Please select a group in order to display the associated CAD files.

Bidding text

METALUNIC V Sinus All-metal Venetian blinds with use of daylight

All-metal construction with self-supporting slats with an attractive sinus shape. Better use of daylight, reduced glare in the typical shading position of about 45°. Lifting and adjustment mechanism integrated in the lateral guides. Lateral lifting mechanism with steel roller chain. Stainless hinge chain for adjusting the slats in any blind position. Two alternative lowering positions, blinds lift in a bright position with horizontal slats. Good obscuration function. Integrated safety locking device in each position. Safety sensing edge prevents destruction of the blind in the event of collisions with obstacles. Slats flanged on both sides with a rolled-in, sound-absorbing sealing lip. Baked-enamel in Premium Colors. Side rails of extruded aluminium, 85 × 45 mm for direct installation, colourless anodised. With sound-absorbing plastic slides on the pivot arms.
Upper rails (housing) of galvanized sheet steel with convenience motor (option: Comfort Drive) or articulated crank drive for the lifting and turning system.
